| Place of Origin: | Hebei |
| Brand Name: | LLHJ |
| Certification: | ISO9001 |
| Minimum Order Quantity: | 500 meters |
|---|---|
| Price: | contact: sales@worldtop.ltd sales@llhjtrading.com |
| Packaging Details: | carton |
| Delivery Time: | Depands on quantites ordered,7-15 days against purchase order in general. |
| Payment Terms: | T/T,L/C |
| Supply Ability: | 4000 meters per day |
PN Expandable Swelling Rubber Water Stop Strip
Introduction:
PN expandable swelling rubber water stop strip is a new waterproof sealing material.It is applicable for construction joint,expansion joint and crack of swimming pool,wastewater treatment,subway,tunnel and other concrete works.
Features:
--It is preset on the interface of construction joint and consequently-cast joint,there is swelled with water and could completely block joint water after secondary casting of concrete(enclosed by concrete)
--The elongation is slow and water pressure resistance is strong.It is applicable for construction in rain season and construction site with much water.
--The construction method is simple.It may have effect of water proofing and seepage resistance when properly utilized.
--The main material is inorganic mineral,and i features aging resistance,anti-corrosion and without pollution.
Specifications:
| Item | Specifications |
| PN-1 | 15mm*20mm |
| PN-2 | 20mm*30mm |
| PN-3 | 20mm*50mm |
| PN-4 | 30mm*50mm |
| PN-5 | 50mm*50mm |
|
NO.
|
Item
|
Index
|
||||
|
B
|
S
|
J
|
||||
|
1
|
Hardness, Shore A
|
60±5
|
60±5
|
60±5
|
||
|
2
|
Tensile Strength, Mpa ≥
|
15
|
12
|
10
|
||
|
3
|
Break and elongation, % ≥
|
380
|
380
|
300
|
||
|
4
|
Compression
|
70°c×24h,% ≤
|
20
|
20
|
20
|
|
|
23°c×168h,% ≤
|
30
|
25
|
25
|
|||
|
5
|
Tear strength,KN/m ≥
|
-45
|
-40
|
-40
|
||
|
6
|
Brittleness temperature ≤
|
35
|
35
|
35
|
||
|
7
|
Air aging
|
70°C×168h
|
Hardness, Shore A
|
8
|
8
|
—
|
|
Tensile Strength,
Mpa ≥
|
12
|
10
|
—
|
|||
|
Break and elongation,% ≥
|
300
|
300
|
—
|
|||
|
100°C×168h
|
Hardness, Shore A
|
—
|
—
|
8
|
||
|
Tensile Strength, Mpa≥
|
—
|
—
|
9
|
|||
|
Break and elongation,%≥
|
—
|
—
|
250
|
|||
|
8
|
Ozone aging 50pphm:20%, 48h
|
Grade 2
|
Grade 2
|
Grade 2
|
||
|
9
|
The bonding of rubber and metal
|
The section is in the elastomer
|
||||
